The operation of the aluminum straw machine
Successfully released-satisfied customers! This is the motto of HGPACKER.
1. HGPACKER was established in 2014 and has more than 10 years of experience in one-stop service of plastic product machinery manufacturing + sales + service (pre-sales and after-sales service);
2. Regularly participate in global international exhibitions, visit foreign customers, understand each other and enhance cooperation.
3. HGPACKER strictly implements ISO9000 and CE certification, forming a complete management and sales model.
4. We have fully staffed and professional after-sales service, you can find the right person, the right skills, and the right method to solve the problem.
5. Take the customer's affairs as ours. As a responsible royal company, we will provide solutions as soon as possible. I wish you trust in HGPACKER and our work, thank you.
The structure and basic principle of the aluminum straw machine
1. Traction component: The key is composed of a number of hard oxidized aluminum rollers and a pair of traction rubber rollers, which have the effect of pulling raw materials for unwinding of finished products. The key is to drive the V-belt by the motor to transmit the driving force to Pull the rubber stick to rotate it.
2. Split tool holder: divided into round blade segmentation and straight knife segmentation. Operate the camshaft according to the control handle to make the round blade move a small amount of shaft diameter, and further adjust the cutting gap between the circular cutting edge and the concave groove of the cushion sleeve. The structure and working principle of the aluminum pipette machine Part 1 The structure and working principle of the pipette machine Knowledge of mechanical auto parts pump valves
3. Frame and transmission device: The key of the frame is composed of upper and lower board walls and supporting and feeding mechanical equipment. The transmission device is mainly used for traction of raw materials and unwinding of finished products. The V-belt is driven by the DC frequency conversion stepless electromagnetic speed control motor, so that the main traction rubber stick and the driven traction rubber stick are close to each other and move the raw materials together. Driven by the active traction roller, the circular blade shafts are made to run at the same time, thereby achieving excellent practical effects of segmentation. Then, according to the lower circular blade shafts, the unwinding A and the unwinding B are driven to carry out simultaneous operation, thereby achieving the purpose of material preparation.
4. Material preparation organization: The key is composed of transmission chains, synchronous wheels, magnetic powder clutches and inflatable shafts. The organization is operated by an independent motor control system and two secret medicines. If the current amount of the magnetic powder clutch is adjusted, the size of the supporting force of the preparation shaft can be changed.
5. Feeding organization and automatic deviation correction system: The key to the feeding organization is composed of a feeding shaft, a supporting point block, a cylinder, a base, and a moving seat up and down. The automatic correction system includes: optical start, correction device guide roller, upper and lower support frame, correction device moving plate, steel ball nut, ball screw, synchronous motor and up and down travel switch.
6. Waste unwinding and sewage discharge: waste can be discharged according to the wind speed of the blower motor.
Featured Products
Collection about HGPACKER
User Reviews
What users say about HGPACKER
Frequently Asked Question
Do you have any question?
(1) The suction tube of the aluminum straw machine is poorly fitted; Check the position of the glue point, check the air pressure of the spray gun, whether the glue head is blocked, etc.; (2) The place where the bag sticks to the tube is blocked; the glue-spraying and extubation electric eyes are blocked, press the empty button to empty the bag; (3) The straw is broken; troubleshoot the problem and wear the straw again.
There are PE (polyethylene) and PP (polypropylene). Generally, there are many soft PEs, and there are many hard PPs that need to be pierced. I have also seen PVC, but very few, generally used to make a lot of patterns of straws.
Yes, we have our own professional design engineers, who can customize the aluminum straw machine according to your requirements and design the aluminum straw machine you are satisfied with.
